Fully Automatic Turbo Pan Mixer
उत्पाद विवरण:
मूल्य और मात्रा
- टुकड़ा/टुकड़े
- टुकड़ा/टुकड़े
- 1
व्यापार सूचना
- प्रति सप्ताह
- हफ़्ता
- Yes
- हमारी नमूना नीति के बारे में जानकारी के लिए हमसे संपर्क करें
- ऑल इंडिया
उत्पाद विवरण
Fully Automatic Turbo Pan Mixer is primarily used for efficient mixing of various materials. It is well engineered and fabricated at our state-of-the-art facility using top notch quality raw materials and latest innovative techniques. It is available in several mixing capacities and specifications to fulfill varying requirements of our clients.
- Grade: Automatic
- Control : PLC Control
- Power Type : Electric
- Voltage: 220- 440 Volt
- Material : Iron, Steel
- Condition : New
- Application : Construction Industry
- Cement Weighing System :300 kg cement hopper
- Water Weighing System :200 kg water hopper
- Additive Weighing System :6 kg Acrylic container
- Total Connected Power : 65 HP
- Dlivery time depend on location
Technical Specification
| VKC 20 4 Bin | VKC 20 4 Bin | VKC 20 4 Bin | VKC 20 4 Bin |
| Output Capacity | 20 cum / Hr. | 30 cum / Hr. | 45 cum / Hr. |
| Output Rate | 18-20 cum / hr. | 28-30 cum/hr. | 43-45 cum / hr. |
| Batch Capacity | 500 Ltr. | 750 Ltr. | 1000 Ltr. |
| Main Mixer Drive | 20 HP | 30 HP | 40 HP |
| Conveyor Motor (Gathering) | 3 HP | 5 HP | 7.5 HP |
| Conveyor Motor (Slinger) | 5 HP | 7.5 HP | 10 HP |
| Cement Screw Con. Motor | 5 HP | 7.5 HP | 12.5 HP |
| Water Pump | 1 HP | 2 HP | 3 HP |
| Air Compressor Motor | 2 HP | 2 HP | 3 HP |
| Admix Pump | 0.5 HP | 0.5 HP | HP |
| Vibration Motor | 3No.x 1/2 HP | 3No.x1/2HP | 3No.x 1/2 HP |
| Total Connected Power | 38 HP | 56 HP | 56 HP |
| Suggest DG Set | 62 KVA | 82 KVA | 120 KVA |
